Evaporative Pad Cooling System Cut/Data Sheet

Installation Manual

Distribution & Return System Features:

• High efficiency system
• Largest self contained PVC return gutter on the market today
• Submersible pumps

Pad Features:

• Water is spread evenly over the pad surface as a film rather than droplets for uniform wetting
• Pad surface dries quickly in absence of water to inhibit micro-organism growth
• Coated pads are tough and durable for repeated cleaning

• Distribution & Return System Features:


  • High efficiency system
  • Largest self contained PVC return gutter on the market today
  • Easy to install, one-piece PVC trough
  • Closed top or open top feature for easy visibility and regulation of water supply
  • Automatic float matches water supply with cooling demands
  • Submersible pumps
  • Easy to clean
  • Simple shutdown for seasonally affected environments
  • Water filter, shutoff, flush valve and bleed-off included in plumbing package
  • Stainless steel and PVC construction to safeguard your investment
  • Optional stainless steel return gutter wall mount brackets

  Pad Features:


  • 6" deep pads specially designed and coated for effective evaporation and maximum durability
  • Water is spread evenly over the pad surface as a film rather than droplets for uniform wetting
  • Easy to remove pads with 30/30 or 45/15 angled fluting
  • Pad surface dries quickly in absence of water to inhibit micro-organism growth
  • Non-porous surface inhibits algae and minerals from attaching to pads
  • Coated pads are tough and durable for repeated cleaning
  • Improved life expectancy over standard pads
  • Easy to install and remove or replace pads

  Additional Information

  How To Size Fan & Shutters System?

  1. First thing is to determine is the amount of air required. This is stated in CFM (Cubic Feet of Air per Minute). In addition, the required Air Changes Per Hour (ACH).  A Greenhouse requires 60-120 ACH's depending on location and weather conditions.
  2. The following formula to determine the CFM's and ACH's required for your greenhouse:
     CFM = Width x Length x Height
     Example: Greenhouse 12' wide X 40' long X 12' High requires 9,600 CFM at 60 ACH, 14,400 CFM at 90 ACH and 19,200 CFM at 120 ACH.
  3. Review the above table. Select the appropriate combination of fan(s) to achieve the necessary CFM rating and ACH. Be sure to match the total CFM output for your exhaust fan(s) to the CFM ratings for your Inlet Shutters. Below are examples of end wall to end wall and side wall to side wall ventilation. Call 888-849-1233 for Free Expert Advice.





  EC100 EC100C EC110 EC110C ECH300 ECH400 ECH500 ECH600 ECH700S ECH800S ECH900S ECH1000S PP10492 ECP133030EC ECP143030EC ECP153030EC ECP163030EC ECP134515EC ECP144515EC ECP154515EC ECP164515EC ECS109

  Call 888-849-1233 for FREE Expert Advice and Factory Direct Pricing.
