JD 412M CONTROLLER | 12 & 16 Stage Ventilation Controls | JD412M (CLICK TO VIEW CUT SHEET & DETAILS) (CALL FOR FREE EXPERT ADVICE & PRICING)

(3 reviews) Write a Review
SKU:
JD412M
Weight:
20.00 LBS
Complete line of Controllers are available. Call 888-849-1233 for Free Expert Advice, Cut Sheet and Factory Direct Pricing.

Description

JD412M and JD412M2 - 16 Stage Ventilation Control

J&D Manufacturing's JD412M series each include 12 relay stages (12 FLA) and four independent variable stages (12 FLA). The JD412M and JD412M2 are used for multiple zone buildings that require fully configurable relay stages for heat/cool, duty cycles, timed events, and curtains/inlets.

JD412M & M2 Cut Sheet

Features:
  • Includes standard 30' temperature sensor (extendable up to 500')
  • Ambient temperature range 32-122°F (0-50°C)

Input Capabilities:
  • Up to 4 inside temperature sensors
  • 1 outside temperature
  • 1 humidity sensor
  • 4 potentiometer inputs

  • Features:

    • Choose the JD412M for 1 HP needs or JD412M2 for 2 HP
    • 8 x 20 character LCD display
    • Fahrenheit or Celsius display
    • Adjustable motor curves
    • Input Capabilities:
                   - Up to 4 inside temperature sensors
                  - 1 outside temperature
                  - 1 humidity sensor
                  - 4 potentiometer inputs
    • Manual override
    • Password security to prevent unauthorized setting changes
    • Adjustable open/close and idle durations (1-900 seconds)
    • 115 or 230 V, 50/60 Hz
    • Includes standard 30' temperature sensor (extendable up to 500')
    • Ambient temperature range 32-122°F (0-50°C)
    • Rugged and sealed enclosure (13" x 13" x 5-1/4")
    • Modular board design allows you to easily replace, repair, and expand individual relay boards while leaving the main board in place
    • Compatible with FarmQuest, FarmSite, and Wi Farm telesystem technologies
    • TWO YEAR LIMITED WARRANTY

    JD412M JD412M2 JD-412M JD-412M2 JD412M-DB JD412M-MB JD412M2-DB JD12111500 JD200410K JD200410K-10 JD200410K-30 JD512M JD200410K-75 JDM010 JD1264 JD412-MB-A JD412-MB-B JD412-MB-C JDRH1

     Complete line of Controllers are available. Call 888-849-1233 for Free Expert Advice, Cut Sheet and Factory Direct Pricing.
